Pocket Series Thermal Imaging Camera

TI-C25

TI-C25 series are the latest advanced technology compact thermal imaging cameras. Widely suited for use in Research, Building Maintenance, Medical, Transport, Archaeological, Agricultural fields and many more.

Portable thermal imaging for quick on-site inspections
Real-time detection of temperature abnormalities
Improves maintenance efficiency and troubleshooting speed
User-friendly touchscreen interface for easy operation
Rugged design suitable for field environments

Application-Based Customization

Engineered for Your Process Conditions

Expert Selection Support

Reliable After-Sales Service

Still Confused What to Buy?

Need help deciding? Download resources to know more about the product.

https://tipl.com/wp-content/uploads/2026/03/TI-C25-Series.pdf

Compact Pocket series
Wide temperature range (-)20 to 650°C
6 Color palettes
3.5 inch TFT color touchscreen
16GB storage
IP67, 2 meters drop resistance
Gravity sensors for horizontal and vertical display modes
Features WiFi, Real time analysis, Data upload, Max and Min temperatures, Line Temperature, Regional Temperature, Alarm
Image modes : Infrared, Visible, Fusion, Picture in Picture
Focus Free

Electrical panel inspection
Preventive maintenance and troubleshooting
HVAC system inspection
Building diagnostics and insulation checks
Industrial equipment monitoring
Research and general-purpose thermography

Model: TI-C25
Imaging Modes: Thermal Image, Visible Image, Picture in Picture, Image Fusion
Detector: Uncooled FPA Infrared Detector (Vanadium Oxide), IR Resolution 256 × 192, Total Pixels 49,152
Thermal Sensitivity (NETD): <50mk @30°C
Lens / Optics: 6.0 mm / F1.0, Field of View ≃ 30° × 22°, Spatial Resolution 2.0 mrad
Imaging Performance: Frame Rate 50Hz, Focus Free, Spectral Range 8μm ~ 14μm ±0.5μm
Display: 3.5 inch TFT color touch-screen with built-in gravity sensors (auto horizontal / vertical UI rotation) and rotation lock
Measurement Functions: Real-time movable points (max, min or standard), movable area (max, min, avg), arbitrary line temperature measurement (resizable, movable & angle orientation), temperature alarm (sound, color), flashlight available
Temperature Range: -20 °C ~ 650°C, Accuracy ±2 °C or ±2% whichever is greater (@25 °C ambient)
Emissivity Correction: Adjustable from 0.01 to 1.0 with measurement correction based on emissivity, ambient temperature, background temperature, humidity and distance
Storage & Format: 16GB built-in storage, image format standard JPEG
Interfaces: WiFi available, USB for charging and data transfer
Power: Built-in rechargeable Lithium-ion battery, operating time >4 hours, USB charging, automatic sleep and shutdown power saving
Environment: Operating temperature -15°C ~ 50°C, storage temperature -40°C ~ 70°C, relative humidity <95% RH non-condensing
Physical: Weight ~200 g, dimensions ~135 × 90 × 26 mm
Protection & Safety: Vibration 2G (IEC 60068-2-6), Shock 30G (IEC 60068-2-27), Drop resistance 2 meters, IP67 encapsulation
Standard Accessories: Manual, NABL Calibration Certificate, USB data cum charging cable, packaging box, power adapter, 16GB USB containing Android based APP, analysis software and manual

Comprehensive Services Using This Product

From installation to ongoing support, we’re with you every step of the way.

Thermography

Infrared imaging for proactive maintenance and safety.

Calibration

Precise calibration ensuring measurement accuracy and compliance.

Industries Using This Product

Our solutions are trusted by top industries to drive growth and improve operations.

Chemicals & Fertilisers

Precision solutions for chemical processes, ensuring compliance and operational efficiency.

Power

Optimizing power plant operations with real-time monitoring and predictive maintenance solutions.

Water

Reliable solutions for water treatment and quality monitoring in industrial applications.

What Customers Say About Us

Excellent Technical Support

The team demonstrated strong application understanding and timely execution. Overall experience has been very satisfactory.

Mr. Rajesh SharmaPlant Head, Cement Division

Reliable Industrial Partner

Solutions were practical and suited to our requirement. Service response has been consistent.

Mr. Amit VermaMaintenance Manager, Steel Plant

Good Project Coordination

Product quality met expectations and installation support was helpful. Communication during execution was smooth.

Mr. Prakash IyerInstrumentation Head, Process Industry

Strong Technical Expertise

The team handled the application professionally. Support during commissioning was commendable.

Ms. Neha GuptaInstrumentation Head, Process Industry

Insights & News

Ensuring Environmental Compliance with CEMS: A Step Ahead

Learn how Continuous Emission Monitoring Systems (CEMS) help industries stay compliant with environmental norms, providing real-time emission data, remote monitoring, and actionable insights for sustainable and responsible manufacturing.

How Predictive Maintenance is Transforming Industrial Efficiency

Discover how advanced monitoring tools like vibration and ultrasound solutions are helping industries move from reactive to predictive maintenance—reducing downtime, extending equipment life, and optimizing productivity across critical operations.

Clients Who Have Transformed Their Operations with This Product

Frequently Asked Questions About This Product

The TI-C25 is used for portable thermal imaging and temperature inspection in industrial and maintenance applications.

The camera measures temperatures from –20°C to 650°C.

Yes. The camera features IP67 protection, compact design, and 2-meter drop resistance, making it ideal for field environments.

Yes. It provides real-time temperature analysis including max, min, area, and line temperature measurements.

Industries include electrical maintenance, HVAC, building inspection, manufacturing, and general industrial applications.
